Smoke and heat extraction system control panels
MBZ 300 CFPP * Smoke and heat extraction control panel for smoke and heat extraction drives with a total power consumption of 10 A to 24 A
- Modular design to allow flexible adaptation to project-specific requirements
- Convenient extension by clicking on other modules in a control unit
- Can be extended by alarm groups, ventilation groups and alarm lines as required
- Depiction of complex smoke and heat extraction scenarios
- Simple service and installation thanks to status display directly on the module
- Configuration software simplifies commissioning and configuration
- Wind direction dependent activation possible (SHEV according to EN 12101-2)
- Conforms to the Chinese stipulations for complex smoke and heat extraction systems (CFPP)
Rechargeable battery capacity 17 Ah/ 24 Ah/ 38 Ah depending on the variant and its settings
Application Areas
- Small to large and networked smoke and heat extraction systems
- Control of electromotive 24 V drives for smoke and heat extraction in the event of a fire
- Control of a controlled natural ventilation
Technical data
| MBZ 300 CFPP | |
| Material | Sheeting |
| Colour | grey RAL 7035 |
| IP rating | IP30 |
| Service temperature | -5 - 40 °C |
| Operating voltage | 230 V AC |
| Number of cores | 3 cores |
| Connection cross-section / mains | 2.5 mm², 1.5 mm² |
| Output voltage | Minimum output voltage according to EN 12101-10 Tab.4, window opener 19.3V / detection circuit 18.2V |
| Residual ripple | 2 % |
| Battery capacity | 38 Ah |
Downloads
GEZE MBZ 300 10A-24A
LABELLING OBLIGATION: © GEZE GmbH
Variants & Accessories
* Notice about the products displayed
The products mentioned above may vary in form, type, characteristics and function (design, dimensions, availability, approvals, standards etc.) depending on the country. For questions please contact your GEZE contact person or send us an E-Mail .
